LINEAR ACTUATORS

Specialising in the production of industrial automation, Hitec Italia provides its customers with numerous products, including linear actuators. The latter, characterised by state-of-the-art technology, represent a cleaner and more efficient alternative to hydraulic and pneumatic solutions.

Get in touch with our office in Carrara if you want to request more information or a no-obligation quote: you can call us or send us a message via WhatsApp.

LINEAR ACTUATORS

The electric linear actuators manufactured by Hitec Italia are designed in such a way that they convert the rotary motion of gears and a ball screw or leadscrew into rectilinear or linear motion. These products enable precise and repeatable operations of:

push/pull;
lifting/lowering;
rotation or positioning of loads.

Linear actuators are commonly used in applications such as agricultural machinery and equipment, medical devices, industrial automation and material handling.

Titolo diapositiva

Scrivi qui la tua didascalia

Pulsante
Titolo diapositiva

Scrivi qui la tua didascalia

Pulsante
Titolo diapositiva

Scrivi qui la tua didascalia

Pulsante

Our actuators are maintenance-free, leak-free and easy to integrate into an automated process.

If you need more detailed information on the technical characteristics of linear actuators or would like to request a no-obligation quotation, please contact the Hitec Italia staff using the form on this website: we will reply as soon as possible, providing you with comprehensive explanations or free and clear cost estimates.

Titolo diapositiva

Scrivi qui la tua didascalia

Pulsante

PNEUMATIC SERVOMOTOR

HLS12-100100-6V (S)

Linear, transmission ratio 100:1, stroke 100 mm, actuator with 5 mm cable (6 V)
Part No.: 41004
Weight: 0.30 lb / 0.13605 kg

SHARE THIS PRODUCT

PRODUCT SPECIFICATIONS

Linear
Control protocol
Weight (g) Min: 56.00
Operating voltage (V) 6.0 V
Motor type With core CC
Circuit
Lead screw 5
Gear ratio 100:1
No-load speed (mm/s) 100:1
No-load current (mA) 13.0
Maximum efficiency point Carico (kg / N): 1.7 / 17

Speed (mm/s): 13.0

Current (mA): 200
Pera Power Point Load (kg / N): 3.1 / 31

Speed (mm/s): 7.0

Current (mA): 300
MAXIMUM FORCE Load (kg /N): 4.2 / 42

Speed (mm/s): 0.00

Current (mA): 400
Stall torque (N) 4.2/42
Maximum static force (N) 200
Stroke specifications (mm) 100
Repeatability (mm) ± 0,5
Maximum side load 15
Dimensions 152.0 x 15.0 x 18.0
Casing material Engineering plastics/tempered metal
Gear material Metal

DOWNLOAD TECHNICAL DATA SHEET

Titolo diapositiva

Scrivi qui la tua didascalia

Pulsante

PNEUMATIC SERVOMOTOR

HLS12-100210-6V (S)

Linear, transmission ratio 210:1, stroke 100 mm, actuator with 5 mm cable (6 V)
Part No.: 41007
Weight: 0.30 lb / 0.13605 kg

SHARE THIS PRODUCT

PRODUCT SPECIFICATIONS

Linear
Control protocol
Weight (g) Min: 56.00
Operating voltage (V) 6.0 V
Motor type With core CC
Circuit
Lead screw 5
Gear ratio 210:1
No-load speed (mm/s) 210:1
No-load current (mA) 6.1
Maximum efficiency point Load (kg / N): 3.6 / 36

Speed (mm/s): 4.5

Current (mA): 200
Pera Power Point Load (kg / N): 7.0 / 70

Speed (mm/s): 3.2

Current (mA): 310
MAXIMUM FORCE Load (kg /N): 8.5 / 85

Speed (mm/s): 2.30

Current (mA): 400
Stall torque (N) 10.0/100
Maximum static force (N) 200
Stroke specifications (mm) 100
Repeatability (mm) ± 0,5
Maximum side load 15
Dimensions 152.0 x 15.0 x 18.0
Casing material Engineering plastics/tempered metal
Gear material Metal

DOWNLOAD TECHNICAL DATA SHEET

Titolo diapositiva

Scrivi qui la tua didascalia

Pulsante

PNEUMATIC SERVOMOTOR

HLS12-100380-6V (S)

Linear, transmission ratio 380:1, stroke 100 mm, actuator with 5 mm cable (6 V)
Part No.: 41015
Weight: 0.30 lb / 0.13605 kg

SHARE THIS PRODUCT

PRODUCT SPECIFICATIONS

Linear
Control protocol
Weight (g) Min: 56.00
Operating voltage (V) 6.0 V
Motor type With core CC
Circuit
Lead screw 5
Gear ratio 380:1
No-load speed (mm/s) 380:1
No-load current (mA) 3.3
Maximum efficiency point Load (kg / N): 6.5 / 65

Speed (mm/s): 2.5

Current (mA): 200
Pera Power Point Load (kg / N): 10.0 / 100

Speed (mm/s): 1.9

Current (mA): 300
MAXIMUM FORCE Load (kg /N): 15.0 / 130

Speed (mm/s): 1.20

Current (mA): 400
Stall torque (N) 18.0/180
Maximum static force (N) 200
Stroke specifications (mm) 100
Repeatability (mm) ± 0,5
Maximum side load 15
Dimensions 152.0 x 15.0 x 18.0
Casing material Engineering plastics/tempered metal
Gear material Metal

DOWNLOAD TECHNICAL DATA SHEET

Titolo diapositiva

Scrivi qui la tua didascalia

Pulsante

PNEUMATIC SERVOMOTOR

HLS12-10050-6V (S)

Linear, transmission ratio 50:1, stroke 100 mm, actuator with 5 mm cable (6 V)
Part No.: HLS12-10050-6V (S)
Weight: 0.30 lb / 0.13605 kg

SHARE THIS PRODUCT

PRODUCT SPECIFICATIONS

Linear
Control protocol
Weight (g) Min: 56.00
Operating voltage (V) 6.0 V
Motor type With core CC
Circuit
Lead screw 5
Gear ratio 50:1
No-load speed (mm/s) 50:1
No-load current (mA) 25.0
Maximum efficiency point Load (kg / N): 1.0 / 10

Speed (mm/s): 19.0

Current (mA): 200
Pera Power Point Load (kg / N): 1.7 / 17

Speed (mm/s): 14.0

Current (mA): 300
MAXIMUM FORCE Load (kg /N): 2.2 / 22

Speed (mm/s): 6.65

Current (mA): 400
Stall torque (N) 2.5/25
Maximum static force (N) 200
Stroke specifications (mm) 100
Repeatability (mm) ± 0,5
Maximum side load 15
Dimensions 152.0 x 15.0 x 18.0
Casing material Engineering plastics/tempered metal
Gear material Metal

DOWNLOAD TECHNICAL DATA SHEET

Titolo diapositiva

Scrivi qui la tua didascalia

Pulsante

PNEUMATIC SERVOMOTOR

HLS12-30100-6V (S)

Linear, transmission ratio 100:1, stroke 30 mm, cable actuator 5 mm (6 V)

Part No.: 41001
Weight: 0.30 lb / 0.13605 kg

SHARE THIS PRODUCT

PRODUCT SPECIFICATIONS

Linear
Control protocol
Weight (g) Min: 34.00
Operating voltage (V) 6.0 V
Motor type With core CC
Circuit
Lead screw 5
Gear ratio 100:1
No-load speed (mm/s) 100:1
No-load current (mA) 13.0
Maximum efficiency point Load (kg / N): 1.7 / 17

Speed (mm/s): 13.0

Current (mA): 200
Pera Power Point Load (kg / N): 3.1 / 31

Speed (mm/s): 7.0

Current (mA): 300
MAXIMUM FORCE Load (kg /N): 4.2 / 42

Speed (mm/s): 0.00

Current (mA): 400
Stall torque (N) 4.2/42
Maximum static force (N) 200
Stroke specifications (mm) 30
Repeatability (mm) ± 0,2
Maximum side load 40
Dimensions 82.0 x 15.0 x 18.0
Casing material Engineering plastics/tempered metal
Gear material Metal・For large aircraft
・Metal gears 1-3 stages
・High-strength metal final-stage gears・Top/centre/bottom aluminium casings
・S.BUS system
・New HPS motor
・High-frequency control
・Speed: 0.12 sec/60° (7.4 V) / 0.13 sec/60° (6.6 V)
・Torque: 74.0kgf・cm (7.4 V) / 68.0 kgf・cm (6.6 V)
・Dimensions/Weight: 40.5×21.0 ×39.4 mm / 82 g

*L'HPS-A702 requires a high instantaneous current to achieve both high output and responsiveness. During intense aerobatic flight, the power line may become unstable in rare cases, so when connecting more than one servo with the S.BUS system, please use a receiver capacitor (16V1800μF) for safety. Please refer to the instruction manual for connection.

*Batteries and BEC cannot be used.

DOWNLOAD TECHNICAL DATA SHEET
